Troubleshooting
When a Master Ejection Error Has Occurred
● Discard the old master, making sure that it
does not touch your clothing.
IMPORTANT
Lift the lever toward you.
The master clamp opens and the edge of the master
will be released from the clamp. If the master is stuck,
release it by hand.
Master clamp
Master
Lever
Return the lever.
Pull the front end of the master toward you and press
the JOG switch intermittently.
Hold the switch down until the master peels off.
JOG switch
Hold the JOG switch down until the drum comes to a stop with a beep.
Close the master ejection box, pressing it until it locks.
To Next Page
