61
Replacing Consumables
● Only use roll masters designed for use in this machine.
● If you do not use the specified roll masters, it may cause decrease in machine
performance or the machine to malfunction.
● Do not put anything heavy on the roll master box as this could scratch the master, causing
the machine to perform master making incorrectly.
● Once the roll master is taken out of the box, install it immediately, otherwise foreign
materials may become attached to the surface of the master and cause the machine to
perform master making incorrectly.
● Do not store roll masters in areas subject to direct sunlight, high/low temperature, and
high/low humidity.
IMPORTANT
Replacing the Roll Master
The message “ROLL-MASTER END” is displayed on the LCD panel when the roll master is
used up. Replace the roll master using the following procedure.
ROLL-MASTER END
Replacing the Roll Master
How to Replace the Roll Master
Master cover
release lever
Master cover
Open the “upper cover”.
Upper cover
Pull the “master cover release lever”.
The master cover will open up.
To Next Page
