Replacing Consumables
Replacing the Drum Unit
Roller
Rail
Lever
Hold the “drum” horizontally and place the drum
guide roller on the rail in the machine.
How to Set Drum Unit
Release the “upper drum shaft” and push the “drum”
in about 10 cm while lifting up the front end slightly.
Hold the “drum” horizontally and push it in gently
until it comes to a stop.
Lift the “lever” toward you while pushing the drum
in.
To Next Page
