● Measured value of the temperature transmitter that corres-
ponds to 20mA (e.g. 200 for a temperature transmitter with
the signal range .50..200°C)
AI:
[
Over-/underrun action]
● Action that is performed in the event of an overrun or under-
run of the assigned analogue input (see input) -> use current
measured value (no restriction) or the overrun/underrun value
(measured value is retained in the event of an overrun/under-
run, until these limits are overrun/underrun once again).
[
Fixed value]
● Temperature that is used if "Fixed value" has been selected
for the source assignment.
[
Standard temperature]
● Temperature to be used for standardisation (default: 0°C).
If the standard temperature in certain application ranges dif-
fers from the default value, this can be set here.
MC0.2: Media pressure [hPa]
[
(4.3.MC0.4.2)]
Upper limit value [°C]
● see above
Lower limit value [°C]
● see above
Offset a0 [°C]
● see above
Slope a1
● see above
Slope a2
● see above
Al: [
Live zero]
● Selection of the living zero point of the assigned analogue in-
put / absolute pressure transmitter (start of the AI signal
range): 0, 2, 4mA.
AI: [
Signal range start]
● Measured value of the absolute pressure transmitter that cor-
responds to the living zero point selected above (e.g. 800 for
an absolute pressure transmitter with the signal range
800..1200hPa)
AI: [
Signal range end]
● Measured value of the temperature transmitter that corres-
ponds to 20mA (e.g. 1200 for a temperature transmitter with
the signal range 800..1200hPa)
AI: [
Over-/underrun action]
● Action that is performed in the event of an overrun or under-
run of the assigned analogue input (see input) -> use current
measured value (no restriction) or the overrun/underrun value
(measured value is retained in the event of an overrun/under-
run, until these limits are overrun/underrun once again).
Fixed value [hPa] [
]
