71
800.788.5572 DuraLabel.com
Troubles hooTing
b. To remove a sheet from the central area of the belt (b), carefully separate
the sheet from the belt surface and withdraw the sheet.
c. To remove a sheet just entering the fuser (c), separate the trailing edge of
the sheet from the belt, push the fuser pressure release lever (d) towards
the front and down to release the fuser’s grip on the sheet, and withdraw
the sheet through the drum cavity area. Then allow the pressure release
lever to rise again.
NOTE: If the sheet is well advanced into the fuser (only a short length is still
visible), do not attempt to pull it back
d. To remove a sheet in the fuser, move the two retaining levers (e) towards the
front of the machine to release the fuser. Withdraw the fuser unit using the
handle (f).
d
e
e
f
