DURKOPP ADLER 171 - Deactivating the Edge Pinker

Operation
50 Operating Instructions 171/173 - 02.0 - 09/2019
4.12.3 Deactivating the edge pinker
Fig. 28: Deactivating the edge pinker
To deactivate the edge pinker:
1. Move the lever (1) to the right.
Make sure the lever (1) snaps into place.
 The edge pinker has been deactivated.
(1) - Lever
①
①
