Operation
44 Operating Instructions 171/173 - 02.0 - 09/2019
4.11.2 Setting the pressure of the carrier roller
The contact pressure of the carrier roller must be adapted to the
relevant sewing material.
Proper setting
The sewing material does not slip and is fed through correctly.
Fig. 24: Setting the pressure of the carrier roller
WARNING
Risk of injury from moving parts!
Crushing possible.
Switch off the machine before setting the
pressure of the carrier roller.
(1) - Cylinder
(2) - Screw
(3) - Fabric deflector
(4) - Carrier roller
