Operating Instructions 171/173 - 02.0 - 09/2019 85
7.12 Electrical connection
Important
The voltage on the type plate of the sewing motor must correspond
to the mains voltage.
7.12.1 Connecting the control
To connect the control:
1. Guide the cable from the machine head through the tabletop
cutout.
2. Connect the cables with the control.
Both the cables and the appropriate plugs are color-coded
and marked with a symbol.
DANGER
Risk of death from live components!
Unprotected contact with electricity can result in
serious injuries or death.
Only qualified specialists may perform work on
electrical equipment.
