SPECIFICATIONS
System
Liquid Types Most clean liquids or liquids containing small amounts of suspended solids or gas bubbles
Velocity Range Bi-directional to greater than 40 FPS (12 MPS)
Flow Accuracy
DTTR/DTTN/DTTH/DTTL:
DTTS/DTTC:
DTTS/DTTC:
±1% of reading or ±0.01 FPS (0.003 MPS), whichever is greater
1 in. (25 mm) and larger – ±1% of reading or ±0.04 FPS (0.012 MPS), whichever is greater
3/4 in. (19 mm) and smaller – ±1% of Full Scale
Temperature
Accuracy
(Energy Models
Only)
Option A:
Option B:
Option C:
Option D:
32…122° F (0…50° C)
32…212° F (0…100° C)
–40…350° F (–40…177° C)
–4…85° F (–20…30° C)
Absolute: 0.22° F (0.12° C)
Absolute: 0.45° F (0.25° C)
Absolute: 1.1° F (0.6° C)
Absolute: 0.22° F (0.12° C)
Difference: 0.09° F (0.05° C)
Difference: 0.18° F (0.1° C)
Absolute: 1.1° F (0.6° C) Difference: 0.45° F (0.25° C)
Absolute: 0.22° F (0.12° C)Difference: 0.09° F (0.05° C)
Sensitivity
Flow: 0.001 FPS (0.0003 MPS)
Temperature:
Option A:
Option B:
Option C:
Option D:
0.03° F (0.012° C)
0.05° F (0.025° C)
0.1° F (0.06° C)
0.03° F (0.012° C)
Repeatability 0.5% of reading
Installation
Compliance
General Safety (all models): UL 61010-1, CSA C22.2 No. 61010-1; (power options A and D only) EN 61010-1
Hazardous Location (power supply options A and D only): Class I Div. 2 Groups C, D, T4; Class II, Division 2, Groups F, G,
T4; Class III Division 2 for US/CAN; Standards: UL 1604, CSA 22.2 No. 213, ANSI/ISA 12.12.01 (2013)
Compliant with directives 2004/108/EC, 2006/95/EC and 94/9/EC on meter systems with integral flow transducers, transducers
constructed with twinaxial cable (all transducers with cables 100 ft (30 m) and shorter) or remote transducers with conduit
Transmitter
Power
Requirements
AC:
DC:
Protection:
95…264 V AC 47…63 Hz @ 17 VA max. or 20…26 V AC 47…63 Hz @ 0.35 A max.
10…28 V DC @ 5 W max.
Auto resettable fuse, reverse polarity and transient suppression
Display
Two line LCD, LED backlit:
Top row 0.7 inch (18 mm) height, 7-segment
Bottom row 0.35 inch (9 mm) height, 14-segment
Icons: RUN, PROGRAM, RELAY1, RELAY2
Flow rate indication: 8-digit positive, 7-digit negative max. Auto decimal, lead zero blanking
Flow accumulator (totalizer):
8-digit positive, 7-digit negative max. Reset via keypad, ULTRALINK, network command or momentary
contact closure
Enclosure
NEMA Type 4 (IP-65)
Construction:
Powder-coated aluminum, polycarbonate, stainless steel, polyurethane, nickel-plated steel mounting
brackets
Size: 6.0 in. W x 4.4 in. H x 2.2 in. D (152 mm W x 112 mm H x 56 mm D)
Conduit Holes: (2) 1/2 in. NPT female; (1) 3/4 in. NPT female; Optional Cable Gland Kit
Temperature –40…131° F (–40…55° C) for line AC power with Ethernet option; –40…149° F (–40…65° C) for all others
Configuration
Via optional keypad or PC running ULTRALINK software
(Note: not all configuration parameters are available from the keypad—for example flow and temperature calibration and advanced
filter settings)
Engineering
Units
Flow-Only Model:
Feet, gallons, cubic feet, million gallons, barrels (liquid and oil), acre-feet, pounds, meters, cubic meters,
liters, million liters, kilograms
Energy Model: Btu, mBtu, mmBtu, tons, kJ, kW, MW
Inputs/Outputs
USB 2.0: For connection of a PC running ULTRALINK configuration utility
RS485: Modbus RTU command set or BACnet® MSTP; Baud rates 9600, 14400,19200, 38400, 56000, 57600, 76800
Ethernet: Optional 10/100 Base T RJ45, communication via Modbus TCP/IP, EtherNet/IP, or BACnet/IP
4-20 mA: 12-bit, internal power, can span negative to positive flow/energy rates
Input: Reset totalizer when input is connected to signal ground
Energy Model:
Total Pulse: Opto isolated open collector transistor
2…28V DC, 100 mA max, 30 ms pulse width up to 16 Hz, 12-bit resolution, can span negative to positive
rates; square-wave or turbine meter simulation outputs. Cannot be used with Ethernet option
Flow-Only Model:
Frequency Output: Open collector, 10…28V DC, 100 mA max, 0…1000 Hz; square wave or turbine
meter simulation
Two Alarm Outputs: Open-collector, 10…28V DC, 100 mA max, congure as rate alarm, signal strength
alarm or totalizer pulse (100 ms pulse width up to 1 Hz max )
Specications
Page 108 May 2016TTM-UM-00136-EN-06
