dynasonics TFX Ultra User Manual

Display Menu (DSP)
The DISPLAY menu parameters control what is shown on the display and the rate at which displayed items alternate
(dwell time).
Parameter Meaning Options Description
DISPLAY Display
FLOW
TOTAL
BOTH
The transmitter will only display the flow rate with the DISPLAY set to FLOW - it will not
display the total flow. The transmitter will only display the total flow with the DISPLAY set
to TOTAL - it will not display the flow rate. By selecting BOTH, the display will alternate
between FLOW and TOTAL at the interval selected in SCN DWL.
TOTAL Totalizer options
POS, Positive Flow Only
NEG, Negative Flow Only
NET, Net Flow
BATCH, Batch Mode
Select POS to view the positive direction total only. Select NEG to view the negative
direction total only. Select NET to display the net difference between the positive direction
and negative direction totals. Select the BATCH to configure the totalizer to count up to
a value that is entered as BTCH MUL. After reaching the BTCH MUL value, the display will
return to zero and will repeat counting to the BTCH MUL value.
SCN DWL
Screen display
dwell time
1…10 seconds
Adjustment of SCN DWL sets the time interval that the display will dwell at FLOW and then
alternately TOTAL values when BOTH is chosen from the display submenu. This adjustment
range is from 1…10 seconds.
BTCH MUL Batch multiplier (Enter a value)
BTCH MUL, Batch Multiplier (Value)
If BATCH was chosen for the totalizer mode, a value for batch accumulation must be
entered. This is the value to which the totalizer will accumulate before resetting to zero
and repeating the accumulation. This value includes any exponents that were entered in
the BSC MENU as TOTAL E.
For example:
1. If BTCH MUL is set to 1000, RATE UNT to LITERS and TOTL E to E0 (liters × 1), then the
batch totalizer will accumulate to 1000 liters, return to zero and repeat indenitely.
The totalizer will increment 1 count for every liter that has passed.
2. If BTCH MUL is set to 1000, RATE UNT to LITERS and TOTL E to E2 (liters × 100), then the
batch totalizer will accumulate to 100,000 liters, return to zero and repeat indenitely.
The totalizer will only increment 1 count for every 100 liters that has passed.
Parameter Conguration Using UltraLink Software
Page 47 May 2016 TTM-UM-00136-EN-06
