Sensor Menu (SEN)
The SEN MENU allows access to the various types of transducers the transmitter can work with. Selecting the proper
transducers in conjunction with the transducer mount XDCR MNT and transducer frequency XDCR HZ is critical to accurate
operation of the transmitter.
Parameter Meaning Options Description
XDC TYPE Transducer Type
DTTR (Use DTTN)
DTTN Used on pipes 2 inches (51 mm) and larger
DTTH High temperature version of DTTN
DTTL Used on pipes 24 inches (600 mm) and larger
For pipes 24 inches (600 mm) and larger the DTTL transducers using a transmission frequency of 500 kHz
are recommended.
DTTL transducers may also be advantageous on pipes between 4…24 inches if there are less quantifiable complicating
aspects such as, sludge, tuberculation, scale, rubber liners, plastic liners, thick mortar, gas bubbles, suspended solids,
emulsions, or pipes that are perhaps partially buried where a V-mount is required.
DT1500 Used with the M5-1500 and D1500 legacy transmitters.
COP TUBE 1/2…1-1/2 in. copper tubing used with DTTS and DTTC small pipe transducers
ASA PIPE 3/4…1-1/2 in. ANSI schedule pipes used with DTTS and DTTC small pipe transducers
TUBING 3/4 in. or larger stainless steel tubing used with DTTS and DTTC small pipe transducers
1/2 TUBE 1/2 in. stainless steel tubing used with DTTS and DTTC small pipe transducers
1/2 PIPE 1/2 in. ANSI schedule pipe (steel, PVC and so on) used with DTTS and DTTC small pipe transducers
1 INCH W 1 in. wetted transducer
2 IN PIPE 2 in. ANSI schedule pipe used with DTTS and DTTC small pipe transducers
2 IN
COPPER
2 in. copper tubing used with DTTS and DTTC small pipe transducers
Security Menu (SEC)
The SEC MENU menu allows access to transmitter functions that may need to be protected from changes.
Parameter Meaning Options Description
TOT RES Totalizer reset
YES
NO
Resets the totalizing displayed on the LCD to zero.
SYS RSET System reset
YES
NO
Restarts the transmitter’s microprocessor. This is similar to power cycling the transmitter.
CH PSWD
Change
password
0…9999
The password comes from the factory set to 0000. When set to 0000 the password function is disabled. By
changing the password from 0000 to some other value (any value between 0001…9999), configuration
parameters will not be accessible without first entering the password value when prompted. If the value is left
at 0000, no security is invoked and unauthorized changes can be made. Access to resetting of the totalizer is
also protected by this password. If the password is lost or forgotten, contact the manufacturer for a universal
password to unlock the transmitter.
Conguration
Page 44 May 2016TTM-UM-00136-EN-06
