Transducers
Construction
DTTR NEMA 6*/IP67
PBT glass filled, Ultem, Nylon cord grip,
PVC cable jacket; –40…250° F (–40…121° C)
DTTC/DTTL NEMA 6*/IP67
CPVC, Ultem, Nylon cord grip,
PVC cable jacket; –40…194° F (–40…90° C)
DTTN IS NEMA 6*/IP67
CPVC, Ultem, Nylon cord grip,
PVC cable jacket; –40…185° F (–40…85° C)
DTTN/DTTL (Submersible) NEMA 6P*/IP68
CPVC, Ultem, Nylon cord grip
Polyethylene cable jacket; –40…194° F (–40…90° C)
DTTH NEMA 6*/IP67
PTFE, Vespel, Nickel-plated brass cord grip
PFA cable jacket; –40…350° F (–40…176° C)
DTTS NEMA 6*/IP67
PVC, Ultem, Nylon cord grip,
PVC cable jacket; –40…140° F (–40…60° C)
*NEMA 6 units: to a depth of 3 ft (1 m) for 30 days max. NEMA 6P units: to a depth of 100 ft (30 m) seawater equivalent
density indefinitely.
Frequency
DTTS/DTTC:
DTTR/DTTN/DTTH:
DTTL:
2 MHz
1 MHz
500 KHz
Cables RG59 Coaxial or Twinaxial (optional armored conduit)
Cable Length 990 ft (300 meter) max. in 10 ft (3 m) increments; Submersible Conduit limited to 100 ft (30 m)
RTDs
(Energy Models
Only)
Platinum 385, 1000 ohm, 3-wire; PVC jacket cable
Installation
DTTN (option N) /DTTR/DTTS/DTTH/DTTC: General (see “Installation Compliance” on page<ÜS>)
DTTN Transducer (option F) and IS Barrier D070-1010-002: Class I Div. 1, Groups C&D T5 Intrinsically
Safe Ex ia; CSA C22.2 No. 142 & 157; UL 913 & 916
Software Utilities
ULTRALINK
Used to configure, calibrate and troubleshoot Flow-Only and Energy models. Connection via USB A/B cable; software is compatible with
Windows® 2000, Windows XP, Windows Vista and Windows 7
Specications
Page 109 May 2016 TTM-UM-00136-EN-06
