Data Link Layer Options:

 BACnet IP, (Annex J)

 BACnet IP, (Annex J), Foreign Device

 ISO 8802-3, Ethernet (Clause 7)

 ANSI/ATA 878.1, 2.5 Mb. ARCNET (Clause 8)

 ANSI/ATA 878.1, RS-485 ARCNET (Clause 8), baud rate(s): ____________

MS/TP master (Clause 9), baud rate(s): 9600, 19200, 38400, 76800

 MS/TP slave (Clause 9), baud rate(s):

 Point-To-Point, EIA 232 (Clause 10), baud rate(s):

 Point-To-Point, modem, (Clause 10), baud rate(s):

 LonTalk, (Clause 11), medium: __________

 Other:

Device Address Binding:

Is static device binding supported? (This is currently necessary for two-way communication with MS/TP slaves and certain

other devices.)  Yes No

Networking Options:

 Router, Clause 6 - List all routing configurations, e.g., ARCNET-Ethernet, Ethernet-MS/TP, etc.

 Annex H, BACnet Tunneling Router over IP

 BACnet/IP Broadcast Management Device (BBMD)

Does the BBMD support registrations by Foreign Devices?  Yes No

Character Sets Supported:

Indicating support for multiple character sets does not imply that they can all be supported simultaneously.

ANSI X3.4

 IBM /Microsoft  DBCS  ISO 8859-1

 ISO 10646 (UCS-2)  ISO 10646 (UCS-4)  JIS C 6226

If this product is a communication gateway, describe the types of non-BACnet equipment/networks(s) that the

gateway supports:

Not supported

Communications Protocols

Page 80 May 2016TTM-UM-00136-EN-06

dynasonics TFX Ultra User Manual
