Eaton M-Max series User Manual

Parameters
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 89
Motor
Note

Default values vary based on actual unit ratings.
PNU ID
Access
RUN Value/Range Description
Factory Setting
(P1.3)
P7.1 113 X — Motor, rated operational current I
e
0.2 x I
e
–2 x I
e
(A) I
e
= Frequency inverter’s rated operational current
(See figure on Page 88.)
P7.2 107 X — Current limit 1.5 x I
e
0.2 x I
e
–2 x I
e
(A) Factory setting: 1.5 x I
e
P7.3 112 X — Motor, rated speed 1720
300–20000 RPM
(min
–1
)
(See figure on Page 88.)
P7.4 120 X — Motor, power factor (cos ) 0.85
0.30–1.00 (See figure on Page 88.)
P7.5 110 X — Motor, rated operating voltage

180–676V (See figure on Page 88.)
Pay attention to the supply voltage and the type of
circuit in the stator winding
P7.6 111 X — Motor, rated frequency 60.00
30–320 Hz (See figure on Page 88.)
