Eaton M-Max series User Manual

M-Max Series Overview
4 M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com
Component Identification
M-Max Series
Item
Number Description
1 Frequency inverters MMX-_
2 Mounting frame (for fieldbus connection) MMX-NET-XA
3 Fieldbus connection:
CANopen XMX-NET-CO-A
PROFIBUS
®
DP with XMX-NET-PS-A screw terminals
PROFIBUS DP with XMX-NET-PD-A Sub-Dm connector
DeviceNet™ XMX-NET-DN-A
4 Communication module MMX-COM-PC
— IP21 kit
I
OK
BACK
RESET
LOC
REM
COMM
AC
D
R
IV
E
ER
R
OR
1
4
2
3
