Appendix A
158 M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com
Cables, Fuses and Disconnect Devices
The cross-sections of the cables and cable protection fuses
used must correspond with local standards.
For an installation in accordance with UL Standards, the
fuses and copper cable that are UL-approved and have a
heat-resistance of 60–75°C are to be used.
Use power cables with insulation according to the specified
mains voltages for the permanent installation. A shielded
cable is not required on the mains side. On the motor side
however, a complete (360°) low-impedance shielded cable is
necessary.
The length of the motor cable depends on the radio
interference class and is a maximum of 30m at M-Max.
CAUTION
Fuses and cables selected must always comply with the
applicable regulations at the installation site.
