Appendix B
180 M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com
Appendix B
Door Panel Keypad Adapter System—Mounting Instructions
Overview
The door keypad is used for remote control drivers. It is installed on the door of a cabinet.
For the installation, you need the following parts. See the figure below.
Door Keypad Mounting Kit
Door Keypad Components
Note: Make sure that you have received all necessary parts.
Item Description
1 Door keypad base
2 Text panel, cool gray
3 Door cable with attached grounding cable
4 Door panel adapter
5 Screws (4 pcs)
12345
