About this Manual
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 1
About this Manual
Writing Conventions
Symbols used in this manual have the following meanings:
In order to make it easier to follow the manual, the name of
the current chapter is shown on the header of the left-hand
page and the name of the current section in shown on the
header of the right-hand page. This does not apply to pages
at the start of a chapter or to empty pages at the end of a
chapter.
In order to make it easier to understand some of the figures
included in this manual, the housing of the frequency
inverter, as well as other safety-relevant parts, have been left
out. However, it is important to note that the frequency
inverter must always be operated with its housing placed
properly, as well as with all required safety-relevant parts.
Please follow the installation instructions in the
AWA8230-2416 installation instructions document.
This manual was created in an electronic format. You can
also order a hard copy version of it.
All the specifications in this manual refer to the hardware and
software versions documented in it.
More information on the series described here can be found
on the Internet under:
www.eaton.com\drives
Abbreviations and Symbols
The following symbols and abbreviations are used in this
manual:
M-Max frequency converters are divided into four voltage
categories:
●
100V (MMX11)
●
200V (MMX12_, MMX32_)
●
400V (MMX34_)
●
575V (MMX35_)
Abbreviation Description
EMC Electromagnetic compatibility
FS Frame size
GND Ground, 0V potential
IGBT Insulated-gate bipolar transistor
PDS Power Drives System
LCD Liquid Crystal Display
PES EMC connection to PE for shielded lines
PNU Parameter number
UL
®
Underwriters Laboratories
