Digital Inputs with External Supply Voltage
(Negative Logic, Sink Type)
Digital Outputs (Transistor)
The transistor output (control signal terminal 13, DO–) can be
supplied with the internal control voltage (+24V) via control
signal terminal 20 (DO+) or with an external DC voltage of up
to +48V. The permissible residual ripple must be less than
±5% U
a
/U
a
. The maximum permissible load current is
50 mA.
Digital Output DO and Connection Examples
(Coupling Relay with Freewheeling Diode:
ETS4-VS3; Item No. 083094)
Connection Example and Operation of DO in
Source and Sink Type
The parameter assignment is described in “Digital Outputs
(P5)”on Page 78.
789
DI1 DI2
DI_COM
6
<50 mA
+24V Out
0V
+24V
S1
S1 = LOGIC–
(Sink Type)
LOGIC
– +
(
±5%
)
U
U
a
a
Ready
<50 mA DO– DO+
13 20
+
+24V
0V
(
±5%
)
U
U
a
a
+24V
0V
<50 mA
20
13
DO–
DO+
Source Type
+24V
0V
<50 mA
20
13
DO–
DO+
Sink Type
