Parameters
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 119
Logic Function
PNU ID
Access
RUN Value/Range Description
Factory Setting
(P1.3)
P13.1 1453 X — LOG function, Selection input A 0
Value range for signal A
0 Deactivated
1 READY, the frequency inverter is ready for operation
2 RUN, the inverter of the frequency inverter is enabled
(FWD, REV)
3 FAULT, error message
Error detected (= STOP)
4 Error message inverted (no error message)
5 ALARM, warning message
(see “Protective Functions (P8)” on Page 90)
6 REV (Reverse run), anticlockwise rotating field active
7 Output frequency = frequency setpoint
8 Motor controller active
9 Zero frequency
Output frequency = 0 (Hz)
10 Frequency monitoring 1
For the frequency ranges set at P5.4 and P5.5
11 Frequency monitoring 2
For the frequency ranges set at P5.6 and P5.7
12 PID monitoring
For the deviation set at P9.17
13 Overtemperature signal
14 Overcurrent control active
15 Overvoltage control active
16 PLC Sequence control active
17 PLC Sequence control, single step completed
18 PLC Sequence control, program cycle completed
19 PLC Sequence control, pause
20 Counter, value 1 reached
The counter value is the trigger value set at P3.21 and
can be reset by activating P3.24
21 Counter, value 2 reached
The counter value is the trigger value set at P3.22 and
can be reset by activating P3.24
22 RUN message active
23 Analog minimum reference error
Message, AL 50 if the value of AI1 and/or AI2 goes below
the 4 mA or 2V setpoint value (live zero) (P2.1 = 1, P2.5 = 1)
Values continued on next page
