Eaton M-Max series User Manual

Appendix A
170 M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com
Motor
Protective Functions
Note

Factory settings dependent on specific drive selected.
PNU ID
Access
Designation Value Range Page
FS
(P1.3)
User
SettingRUN ro/rw
P7.1 113 X rw Motor, rated operational current 0.2 x I
e
–2 x I
e
(see motor rating plate)
89 I
e
P7.2 107 X rw Current limit 0.2 x I
e
–2 x I
e
89 1.5 x I
e
P7.3 112 X rw Motor, rated speed 300–20000 min
–1
(see motor rating plate)
89 1720
P7.4 120 X rw Motor, power factor (cos ) 0.30–1.00
(see motor rating plate)
89 0.85
P7.5 110 X rw Motor, rated operating voltage 180–500V
(see motor rating plate)
89

P7.6 111 X rw Motor, rated frequency 30–320 Hz
(see motor rating plate)
89 60.00
PNU ID
Access
Designation Value Range Page
FS
(P1.3)
User
SettingRUN ro/rw
P8.1 700 X rw Analog minimum reference error
(live-zero)
0 = Deactivated
1 = Alarm
2 = Fault, stop according to P6.8
90 1
P8.2 727 X rw Undervoltage error Like P8.1 90 2
P8.3 703 X rw Ground fault Like P8.1 90 2
P8.4 709 X rw Stall protection Like P8.1 91 1
P8.5 713 X rw Underload protection Like P8.1 91 0
P8.6 704 X rw Motor, temperature protection Like P8.1 91 2
P8.7 705 X rw Motor, ambient temperature –20° to 100°C 91 40
P8.8 706 X rw Motor, cooling factor at
zero frequency
0.0–150% 91 40
P8.9 707 X rw Motor, thermal time constant 1–200 min 91 45
P8.10 1430 X rw Analog minimum reference error,
reaction time
0.0–10.0s 93 0.5
P8.11 1473 X — (Not used) — — —
P8.12 714 X rw Underload low torque limit 10.0–150% 93 60.0
P8.13 715 X rw
Underload, low torque limit at
zero frequency
10.0–150% 93 10.0
P8.14 733
X rw Fieldbus error Like P8.1 94 2
P8.15 734 X rw Fieldbus interface error Like P8.1 94 2
