Parameters
M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com 67
Default I/O
Parameter Selection (P1)
In the parameter selection (P1), you can choose between the
factory set quick configuration (P1.1 = 1) with a reduced
parameter set and all parameters (P1.1 = 0).
The setting of the parameters with the quick configuration
(P1.1 = 1) is guided by a Quickstart Wizard. (A listing of
parameters is on Page 66.) Each executed parameter must
be processed in succession up to frequency display M1.1.
A return to a previous parameter is not possible here. The
preset application parameters are selected under P1.2.
Only when the quick start assistant (M1.1) is completed can
the parameters be called again and then also individually.
With P1.1 = 0 (all parameters) and P1.2 = 0, 1, 2, or 3, you
can link the predefined application values with all
parameters.
Every single parameter value is reset to factory settings
every time that the application menu is activated.
Parameter Selections
Designation Terminal Function Parameter Designation Terminal Function Parameter
DI1 8 Start Fwd P3.1, P3.2 DI6 16 PID Controller Deactivate P3.12
DI2 9 Stop/Start Rev P3.1, P3.3 RO1 (NO) 22/23 Run P5.1, P5.10
DI3 10 Fixed Frequency B0 (12 Hz) P3.9, P10.2 RO2 (NO/NC) 24/25/26 Fault P5.2, P5.11
DI4 14 Fixed Frequency B1 (18 Hz) P3.10. P10.3 DO 13 Ready P5.3, P5.9
DI5 15 Fault Reset P3.7
PNU ID
Access
RUN
Value/
Range Description
Factory Setting
(P1.3)
P1.1 115 — Quick start parameters 1
0 All parameters
All parameters are shown and can be changed. Exit from Quickstart.
1 Only quick configuration parameters
Only the selected parameters of the quick configuration are shown and can
be changed (see Page 66 for list of parameters)
P1.2 540 X — Application
(See listing of the predefined application parameters in the table on
Page 66)
0
0 Basic
1 Pump drive
2 Fan drive
3 High load (for example, hoisting or conveyor)
P1.3 1472 X — Country specific default settings 1
0 EU (Europe, 50 Hz networks)
1 NA (North America, 60 Hz networks)
— The country specific factory setting takes into account the frequency
based parameters in relation to 50 and 60 Hz networks:
PNU Designation P1.3 = 0 P1.3 = 1
P6.4 Maximum frequency 50 Hz 60 Hz
P7.3 Motor, rated speed 1440 RPM 1720 RPM
P7.6 Motor, rated frequency 50 Hz 60 Hz
P11.2 Cut-off frequency 50 Hz 60 Hz
P11.4 V/Hz characteristic curve, mean
frequency value
25 Hz 30 Hz
P14.3 Motor (2PS) nominal speed 1440 RPM 1720 RPM
P14.6 Motor (2PS) nominal frequency 50 Hz 60 Hz
P14.8 Maximum frequency (2PS) 50 Hz 60 Hz
