Eaton M-Max series User Manual

Appendix A
176 M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com
Second Parameter Set
Note

Factory settings dependent on specific drive selected.
PNU ID
Access
Designation Value Range Page
FS
(P1.3)
User
SettingRUN ro/rw
P14.1 1347 X rw Motor rated current (2PS) 0.2 x I
e
–2 x I
e
(see motor rating plate)
121 I
e
P14.2 1352 X rw Current limit (2PS) 0.2 x I
e
–2 x I
e
121 1.5 x I
e
P14.3 1350 X rw Motor rated speed (2PS) 300 … 20000 min
–1
(see motor rating plate)
121

P14.4 1351 X rw Motor power factor (cos ) (2PS) 0.30–1.00
(see motor rating plate)
121

P14.5 1348 X rw Motor rated operating voltage (2PS) 180–500V
(see motor rating plate)
121

P14.6 1349 X rw Motor nominal frequency (2PS) 30–320 Hz
(see motor rating plate)
121 60.00
P14.7 1343 X rw Minimum frequency (2PS) 0.00–P14.8 Hz 121 0.00
P14.8 1344 X rw Maximum frequency (2PS) P14.7–320.00 Hz 121 60.00
P14.9 1345 X rw Acceleration time (2PS) (acc3) 0.1–3000s 121 3.0
P14.10 1346 X rw Deceleration time (2PS) (dec3) 0.1–3000s 121 3.0
P14.11 1355 X rw V/Hz characteristic curve (2PS) 0 = Linear
1 = Squared
2 = Configurable
122 0
P14.12 1354 X rw Torque increase (2PS) 0 = Deactivated
1 = Activated
122 0
P14.13 1353 X rw Motor temperature protection
(2PS)
0 = Deactivated
1 = Alarm
2 = Fault, stop according to P6.8
122 0
P14.14 1469 X rw Motor ambient temperature (2PS) –20° to 100°C 122 40
P14.15 1470 X rw Motor cooling factor at zero
frequency (2PS)
0.0–150% 122 40.0
P14.16 1471 X rw Motor thermal time constant (2PS) 1–200 min 122 45
