Appendix B
184 M-Max Series Adjustable Frequency Drive MN04020003E—October 2013 www.eaton.com
Approximate Dimensions in inches (mm)
Door Keypad Dimensions
0.87
(22.0)
0.71
(18.0)
3.94
(100.2)
2.26
(57.4)
2.77 (70.3)
4.92 (125.0)
Front View Side View
