EZ800/EZD Control Commands
MN05013001E176
Table 112: Operand overview
Table 113: Index 0 – Bit IO
Index
(hex)
Operand Read Write
00 Bit IO, J Table 113 ×
01 Mode/Parameters,
J Table 114
×
02 Setpoint 1:
Time setpoint 1
I1 × c
1
03 Setpoint 2:
Time setpoint 2
(with timing relay with
2 setpoints)
I2 × c
1
04 Actual value:
Time elapsed in Run
mode
QV ×
1) The value can only be written if it is assigned to a constant in
the program.
J
The data for index 2 to 4 is transferred as a 32-bit value in
Intel format (Data 1 – Low Byte to Data 4 – High Byte).
Bit 7 6 5 4 3 2 1 0
FB input Data 1 – – – – – ST
1
EN
2
RE
3
FB output Data 3 – – – – – – – Q1
4
1) Stop, the timing relay is stopped (Stop coil)
2) Enable, the timing relay is started (trigger coil)
3) Reset, the timing relay is reset (reset coil)
4) Switch contact
