Appendix 2: Technical Specification
Introduction
The EC-JET Continuous Ink Jet Printer is a fast, reliable, non-contact printer capable of applying
sell by dates, batch codes and other variable information to a wide range of substrates on the
production line.
Technical Data
Cabinet
Top cover： Stainless steel grade 304 (Special surface)
Dimensions
External height： 555mm
External depth： 305mm
External width： 330mm
Weight
Printer weight： 25.5kg（excluding ink, solvent and packaging）
Power Requirements
115V，Voltages range: 85~132Vac，50/60Hz。
230V，Voltages range: 170~264Vac，50/60Hz。
This equipment is a Class 1 earthed Electrical connections at the rear of the cabinet comply with
the extra low voltage safety requirements.
WARNING: THIS PRINTER MUST BE EARTHED/GROUNDED. (Acquired
EN60950 Certificate)
Environmental
Operating temperature: -5 to +45 Celsius ambient
Humidity range: Up to 90% relative humidity, non-condensing
Acoustic emission: Less than 70DB
Ink System
Construction
