Appendix 1: Installation & Setting Up
This appendix is to help you install and set up the printer. Normally this procedure will be carried
out by EC-JET Service Engineers when commissioning a new printer.
These notes are provided as a guide to be used if the printer is relocated or changes are made to
ancillary equipment. Guarding and safety interlocks should all be in place and working correctly.
EC-JET can accept no liability for damage to either machine or personnel in the event of the
printer being installed, moved or maintained by unauthorized and/or untrained personnel.
If you are unsure of any procedure it is recommended that you contact your local EC-JET
distributor.
1.1 Unpacking the System
Please carefully remove the cardboard packaging and check for the following contents:
● EC-JET Printer
● EC-JET User Manual, a guide to quick use
● Packing list
● Final test print sample sheet
● Total Quality Plan packing card
● Key for cabinet, specified cleaning set, air filter set
1.2 Where to Put the Printer
The EC-JET printer must be sited on a firm, solid base (preferably a EC-JET cabinet or mounting
table) and with a clean power supply, i.e. free from electrical interference.
The printer physical dimensions, in millimeters, are as follows:
555 (high) x 305 (deep) x 330 (wide)
The printer weighs 23.5 kg (not including ink or packaging).
1.3 Accessories
The following accessories are available for purchase with the EC-JET printer:
● RS232 Communication Cable - allows multiple, remote printer control from Windows
based PC system.
● Shaft Encoder - enables even print width at uneven line speeds.
● Photocell - detects presence of product.
● Printhead Gantry.
● Positive Air Kit - to prevent condensation and dust interfering with print quality.
For a full list of all available accessories, please contact EC-JET or your EC-JET distributor.
