9.3.5. 2.03 Velocity Of Drop（VOD）
This failure may occur when the jet is being started.
Possible causes
● Misaligned jet.
Carry out the nozzle clear procedure described in the Troubleshooting section of
this manual. (see “Troubleshooting - Clearing the Print head Nozzle”).
● Print head code or modulation values set incorrectly.
Check the Print head and Modulation values printed on the print head serial number
label found on the conduit, with the stored values. (see “Changing the System
Setup”).
● Build-up of ink on the sensors.
Clean the printhead.
● Blocked filter.
Contact your local EC-JET distributor for assistance.
9.3.6. 2.04 300V Power Supply
Possible cause
● The 300 volt power supply output is out of tolerance or has failed.
Contact your local EC-JET distributor.
9.3.7. 2.05 Temperature/Deflector
A failure has occurred which the printer has not been able to fully identify (see Print Failures
“2.00” and “2.01”).
9.3.8. 2.06 Ink Tank Empty
This failure occurs when the ink level sensor has been indicating low for a predetermined time.
Micro 8 hours
Midi 8 hours
Macro 3 hours
This prevents the ink from running out completely if the user fails to top up the ink reservoir
following an “Ink Low” error (see System Warning “3.03”). This failure only occurs when the jet
is running since the jet cannot be started when the ink is low.
9.3.9. 2.16 Internal Spillage Fault
This may occur either at switch on, or during normal running. A sensor within the ink system
detects the unwanted presence of ink or solvent within the cabinet tray.
Possible causes
● The ink or solvent tanks have been overfilled.
● A leak has developed within the ink system.
● Leak sensor is shorted or has failures.
● A lure fitting has become loose on the main filter or damper.
