4.4. Constant Speed(m/min)
Value of speed of production line.
This parameter only applies to fixed speed of speed of production line.
4.5. Pulse Count Per Round of Shaft Encoder(ppr)
It is a pulse count after the shaft encoder rotates for one round.
This parameter only applies to (production line) setting as shaft encoder.
4.6. Perimeter of Shaft Encoder(mm)
Perimeter of shaft encoder= 3.14 * diameter of shaft encoder.
This parameter only applies to the speed of production line being shaft encoder.
4.7. Printing Trigger
Photocell edge:
The printer prints data when the signal of photocell edge is detected.
Photocell level:
The printer prints data when the signal of photocell level is detected.
Interior:
Trigger by printer automatically, continue printing data, and don’t need photocell.
Remote:
Control the printing by communication command.
4.8. Aux In
Off
Not available.
Resets SN
The series number of current printing data will reset if the signal of photocell edge is detected;
Horizontal Reverse
Change the horizontal direction of current printing data and the data direction is based on the Aux
In level.
Vertical Reverse
Change the vertical direction of current printing data and the data direction is based on the Aux In
level.
Horizontal and Vertical Reverse
Change the horizontal and vertical direction of current printing data and the data direction is based
on the Aux In level.
