F15 Series Fetal & Maternal Monitor Service Manual Maintenance
- 19 -
Chapter 5 Maintenance
5.1 Maintenance Inspection
(1) Visual Inspection
 Check the monitor and accessories to see if there is any visible damage that may affect
patient’s safety.
 Check all the outer cables, power socket and power cables.
 Check if the monitor functions properly.
If any damage is detected, replace the damage part(s) or contact EDAN immediately.
(2) Routine Inspection
The overall check of the monitor, including the safety check and functional check, should be
performed by qualified personnel every 6 to 12 months, and each time after service.
The equipment should undergo periodic safety test to insure proper patient isolation from live
parts. This should include leakage current measurement and insulation testing. The recommended
testing interval is once a year or as specified in the institution’s test and inspection protocol.
Patient Leakage Current (Limit) (CF applied part)
N.C. S.F.C.
d.c. 10µA 50µA
a.c. 10µA 50µA
Patient Leakage Current (Limit) (BF applied part)
N.C. S.F.C.
d.c. 10µA 50µA
a.c. 100µA 500µA
Patient Auxiliary Current (Limit) (CF applied part)
N.C. S.F.C.
d.c. 10µA 50µA
a.c. 10µA 50µA
Patient Auxiliary Current (Limit) (BF applied part)
N.C. S.F.C.
d.c. 10µA 50µA
a.c. 100µA 500µA
(3) Mechanical Inspection
Make sure all exposed screws are tightly fixed.
Check the external cables for splits, cracks or signs of twisting.
Pay particular attention to the supply socket. Replace any cable that shows serious damage.
5.2 Maintenance of the Monitor
Keep the exterior surface of the monitor clean, free of dust and dirt.
The gathering of dew on the screen may occur with abrupt temperature or humidity changes. A
stable environment is recommended.
