F15 Series Fetal & Maternal Monitor Service Manual Troubleshooting
- 36 -
Bad connection of
electrodes.
Check the connection.
TOCO&MECG Transducer
defective.
Replace the TOCO&MECG
Transducer.
Main control board
defective.
Replace the main control board.
7.11 SpO2 Monitoring Failures
Phenomenon
Possible Cause
Solution
No SpO
2
waveform or
numeric value.
SpO
2
transducer defective.
Replace the SpO
2
transducer.
Bad connection of SpO
2
cable.
Check the connection.
iM X12 parameter board
defective.
Replace the iM X12 parameter
board.
Main control board
defective.
Replace the main control board.
7.12 NIBP Monitoring Failures
Phenomenon
Possible Cause
Solution
The cuff fails to be inflated.
Bad connection of the cuff,
the air hose and the NIBP
socket.
Check the connection from outside.
Bad connection of the iM
X12 board to the NIBP
socket.
Check the connection from inside.
Cuff or extension tube
defective.
Replace the damaged part(s).
Air pump, air valve leak.
Replace pump valve module.
iM X12 parameter board
defective.
Replace the iM X12 parameter board.
Main control board
defective.
Replace the main control board.
No NIBP numeric values.
iM X12 parameter board
defective.
Replace the iM X12 parameter board.
Air pump, air valve leak.
Replace pump valve module.
Main control board
defective.
Replace the main control board.
