EDAN F15 Series Service Manual

F15 Series Fetal & Maternal Monitor Service Manual Renewal Parts
- 65 -
Appendix 1 Renewal Parts
CAUTION
Only connect the renewal parts supplied by EDAN to the monitor.
Repair Part
Part Number
F15 bottom interface board (not
configured with RF module)
02.03.221006
F15 bottom interface board
02.03.220833
Power module
02.01.214734
F15 DC-DC transfer board
02.03.220839
Loudspeaker
01.14.104873
Fan
01.58.472174
Wireless AP module
02.03.221158
Printhead
01.17.114392
Main control board （ wireless
model）
02.03.452576
Main control board
02.03.221003
Screen assembly
02.04.244389
Wireless transducer bracket
assembly
02.04.244394
AP/IP transducer socket board
PCBA assembly
02.01.215557
EDAN transducer socket board
PCBA assembly
02.01.215555
NELL transducer socket board
PCBA assembly
02.01.215556
