F15 Series Fetal & Maternal Monitor Service Manual Troubleshooting
- 34 -
The paper drawer is not
closed properly.
Push the drawer back in position.
Blank, blurry or incorrect
traces.
Paper is not correctly
loaded.
Reload paper correctly.
The printhead adjusting nuts
are lopsided.
Adjust the printhead adjusting nuts.
Print head defective.
Replace the printhead.
Improper paper settings of
the monitor.
Set paper style according to section
5.12 Changing Paper Style.
7.6 Network Failures
Phenomenon
Possible Cause
Solution
The monitor can not connect
to a network.
The bottom interface board
defective.
Replace the bottom interface
board.
Bad connection between the
bottom interface board and main
control board.
Check the connection.
Main control board defective.
Replace main control board.
Overlapped device no. in the
network.
Change device no. of the
monitor.
Incorrect sever IP setting.
Set server IP correctly.
7.7 Alarm Failures
Phenomenon
Possible Cause
Solution
No audible alarm is activated.
The audible alarm is temporarily
disabled.
Switch on the audible alarm.
Loudspeaker or wire defective.
Replace the loudspeaker or the
wire.
The alarm indicator stays off.
Alarm indicator board defective.
Replace alarm indicator board.
No audible alarm or visual
alarm is activated.
Program defective.
Update the software.
