EDAN F15 Series Service Manual

F15 Series Fetal & Maternal Monitor Service Manual Principle Introduction
- 21 -
Chapter 6 Principle Introduction
6.1 System Principle Block Diagram
F15 series fetal&maternal monitor consists of the AC-DC power board, DC-DC transfer board,
battery, fan, main control board, thermal printer, display/touching module, bottom interface
board, loudspeaker, pump&valve assembly, iM X12 parameter board, transducer socket board
and wired transducer/all parameter accessories. Here is the system principle block diagram:
AC-DC
Power
Board
Main Control Board
DC-DC
Transfer
Board
Bottom Interface Board
Tra
nsd
uce
r
Soc
ket
Boa
rd
iM X12
Board
Batt
ery
Pump&Valve
Assembly
Loudspeake
r
Fan
Thermal Printer
Display/touching module
Acce
ssor
y/Tr
ansd
ucer
F15 Air series fetal&maternal monitor consists of the AC-DC power board, DC-DC transfer
board, battery, fan, main control board(with AP module), thermal printer, display/touching
module, bottom interface board, loudspeaker, wireless transducer/NBIP&SpO2 fetal&maternal
module/all parameter accessories. Here is the system principle block diagram:
