EDAN F15 Series Service Manual

F15 Series Fetal & Maternal Monitor Service Manual Principle Introduction
- 28 -
Sensor Type
YSI-10K
Refresh Time
Every 1 ~ 2 second(s)
6.1.6 Edan Transducer Socket Board (wired model only)
The EDAN transducer socket board locates on the left of the lower case, i.e. the left of the
monitor. It communicates between the main control board and external transducer accessories. Its
function is to isolate the signal of accessories, power supply and ground, and transfers collected
SpO2 and TEMP signals to iM X12 parameter board.
Here is the principle block diagram:
Transducer Interface*4
（support any fetal
transducer at any
interface）
Reflective
Interrupter*4
Communicate
signal*4
Isolation
Circuit
LDO
+5V_IS
O
MARK_ISO、
EXT_ISO
Reflective
Interrupter*2
MARK、EXT
Socket to
connect with
lower case
interface
board
+12V time-
delay
circuit
+5V_I
N
+12V_I
N
+12V
+5V5
Supply power
for transducer
accessories
Figure 6-5 EDAN Transducer Socket Board Principle Block Diagram
Note:
The US, TOCO&MECG and DECG&IUP transducer can be plugged in and out at any of the 4
transducer interface.
6.1.7 NELL Transducer Socket Board (wired model only)
The NELL transducer socket board locates at left side of the lower case, i.e. the left of the
monitor. The NELL transducer socket board communicates between the main control board and
external transducer accessories. Its function is to isolate the signal of accessories, power supply
and ground, and transfers collected SpO2 and TEMP signals to iM X12 parameter board.
Here is the principle block diagram:
