EDAN F15 Series Service Manual

F15 Series Fetal & Maternal Monitor Service Manual Principle Introduction
- 30 -
Wireless
Charging Analog
Front End
Wireless
Charging
Transmitter
Coil
Wireless Charging
Controller
NFC Controller
NFC
Transmitter
Coil
Identificatio
n Controller
Fan
Power
Supply
Figure 6-7 Wireless Charging Board Principle Block Diagram
6.2 Interface
On the rear panel of the monitor, there are two interfaces and an antenna:
 USB *2
 RJ45 interface (NETWORK)
 HDMI interface
 DB15 interface
 485 Antenna (optional for domestic sales)
6.2.1 DB15 Interface
All the monitors are configured with a DB15 interface. It is used to connect the monitor to a
computer for monitoring information collection, or to an obstetrical monitoring system such as
MFM-CNS.
6.2.2 Antenna
If the monitor has a built-in wireless module, an antenna will be configured.
It is used to send signals of the bedside monitor to the obstetrical monitoring system.
6.2.3 RJ45 Interface
All the monitors are configured with a RJ45 interface.
It is used to connect the monitor to a computer for updating or monitoring information collection,
or to an obstetrical monitoring system such as MFM-CNS.
