1 Switch Description
This chapter includes these sections:
◆ “Overview” on page 10
◆ “Key Technical Specifications” on page 13
◆ “Data Center Deployment” on page 14
Overview
Thank you for choosing the ECS5610-52S switch system. This switch is built with
leading-edge technology to deliver reliable high-performance connectivity for
your data network.
The ECS5610-52S switch is a high-performance top-of-rack switch, designed for
data center operating environments. The switch provides 48 10G Ethernet Small
Form Factor Pluggable Plus (SFP+) transceiver slots, and four 40G Quad-SFP+
(QSFP+) ports. The switch also includes replaceable dual power supply units and a
fan tray module.
The switch supports a full set of Layer 2 switching, data center bridging, and Layer 3
routing features. The switch can be deployed as a top-of-rack (TOR) or distributed
spine switch to form a network fabric that can reduce infrastructure expenses and
power consumption in the data center. This network fabric can be used to
interconnect tens of thousands of servers delivering cloud computing services.
The switch also offers an option of front-to-back (F2B) or back-to-front (B2F) airflow
cooling for rack deployment with either blade servers or other switches, allowing
cool aisles to be maintained without creating “hot loops.”

Edge-Core AS5610-52X Specifications

Operating Environment

operating temperature	0° C to 40° C
storage temperature	-40° C to 70° C
operating humidity	5% to 95% (non-condensing)

Power

AC input voltage	100-240 VAC
AC input frequency	50-60 Hz
AC input current	6-3 A
DC output 5V	3 A
DC output 12V	33 A
power consumption	165 Watts maximum
maximum current at 100 VAC	6 A
maximum current at 240 VAC	3 A
power supply power	400 Watts @ 240V/100V per module

Weight and Dimensions

width	438.4 mm
depth	473 mm
height	43.4 mm
weight	8.395 kg
power supply width	54.5 mm
power supply depth	220 mm
power supply height	40.25 mm
