Chapter 3 | Switch Chassis
Switch Cooling Requirements
– 27 –
Rack Cooling When mounting the switch in an enclosed rack or cabinet, be sure to check the
following guidelines to prevent overheating:
◆ Make sure that enough cool air can flow into the enclosure for the equipment it
contains.
◆ Check that the rack or cabinet allows the hot air to exit the enclosure (normally
from the top) without circulating back into equipment.
◆ If the enclosure has sides or doors with ventilation holes, make sure they are
not blocked by cables or other obstructions.
◆ Route cables within the rack or cabinet to maximize the air flow.
◆ When possible, do not completely fill the rack or cabinet with equipment, allow
some unused space within the enclosure for better air flow.
Fan Tray Module The fan tray module is an important part of the switch air cooling system. A fan tray
module must be installed in the switch at all times. If a fan should fail, the whole fan
tray module must be replaced as soon as possible.
You must install the fan tray module in the switch that matches the airflow
direction of the installed power supply units. The available fan tray modules are
listed below:
◆ ECS5610-52SS-FANTRAY (front-to-back airflow)
◆ ECS5610-52SSR-FANTRAY (back-to-front airflow)
Caution: The switch includes plug-in power supply and fan tray modules that are
installed into its chassis. All installed modules must have a matching airflow
direction. That is, all modules must have a front-to-back (F2B) airflow direction, or
all modules must have a back-to-front (B2F) airflow direction. The airflow direction
of PSUs and fan trays is indicated by labels on the modules.
The removable fan tray, located in the rear of the switch, includes four fixed fans
and supports fan speed control. The fan speed is dynamically controlled as a
function of temperature: the higher the internal temperature, the faster the speed
of the fans. The fan tray module does not include LED indicators.

Edge-Core AS5610-52X Specifications

Operating Environment

operating temperature	0° C to 40° C
storage temperature	-40° C to 70° C
operating humidity	5% to 95% (non-condensing)

Power

AC input voltage	100-240 VAC
AC input frequency	50-60 Hz
AC input current	6-3 A
DC output 5V	3 A
DC output 12V	33 A
power consumption	165 Watts maximum
maximum current at 100 VAC	6 A
maximum current at 240 VAC	3 A
power supply power	400 Watts @ 240V/100V per module

Weight and Dimensions

width	438.4 mm
depth	473 mm
height	43.4 mm
weight	8.395 kg
power supply width	54.5 mm
power supply depth	220 mm
power supply height	40.25 mm
