Edge-Core AS5610-52X Installation Guide

– 54 –
A Troubleshooting
Diagnosing LED Indicators
System Self-Diagnostic Test Failure
If the Diag LED indicates a failure of the system power-on-self-test (POST), you can
use a console connection to view the POST results. The POST results may indicate a
failed component or help troubleshoot the problem. For more information on
connecting to the console port and using the CLI, refer to the Administrator’s Guide.
Note a POST failure normally indicates a serious hardware fault that cannot be
rectified or worked around. If you encounter a POST failure, you should contact
your dealer for assistance.
Table 14: Troubleshooting Chart
Symptom Action
PSU1/PSU2 LED is Off
◆
Check connections between the PSU, the power cord and the wall
outlet.
◆
Contact your dealer for assistance.
PSU1/PSU2 LED is on
Amber
◆
Power cycle the PSU to try and clear the condition.
◆
Replace the PSU.
Diag LED is on Amber
◆
Power cycle the switch to try and clear the condition.
◆
If the condition does not clear, contact your dealer for assistance.
Fan LED is on Amber
◆
Check fans in the fan tray.
◆
Replace the fan tray as soon as possible.
Link/Act LED is Off
◆
Verify that the switch and attached device are powered on.
◆
Be sure the cable is plugged into both the switch and
corresponding device.
◆
Verify that the proper cable type is used and its length does not
exceed specified limits.
◆
Check the attached device and cable connections for possible
defects. Replace the defective cable if necessary.

Edge-Core AS5610-52X Specifications

Operating Environment

operating temperature	0° C to 40° C
storage temperature	-40° C to 70° C
operating humidity	5% to 95% (non-condensing)

Power

AC input voltage	100-240 VAC
AC input frequency	50-60 Hz
AC input current	6-3 A
DC output 5V	3 A
DC output 12V	33 A
power consumption	165 Watts maximum
maximum current at 100 VAC	6 A
maximum current at 240 VAC	3 A
power supply power	400 Watts @ 240V/100V per module

Weight and Dimensions

width	438.4 mm
depth	473 mm
height	43.4 mm
weight	8.395 kg
power supply width	54.5 mm
power supply depth	220 mm
power supply height	40.25 mm
