Edge-Core AS5610-52X Installation Guide

– 7 –
Figures
Figure 1: Front Panel 11
Figure 2: Rear Panel 12
Figure 3: Cloud Data Center Deployment 14
Figure 4: Converged Ethernet Data Center Deployment 15
Figure 5: F2B Airflow Cooling 15
Figure 6: B2F Airflow Cooling 16
Figure 7: Installing the Switch in a Rack 19
Figure 8: Connecting AC Power 20
Figure 9: System LEDs 21
Figure 10: Console Port 21
Figure 11: Making a Connection to a QSFP+ Transceiver 22
Figure 12: Attaching the Brackets 25
Figure 13: Installing the Switch in a Rack 25
Figure 14: Switch Cooling 26
Figure 15: Fan Tray 28
Figure 16: AC Power Supply Module 30
Figure 17: Power Supply Module LED 30
Figure 18: AC PSU and Power Socket 32
Figure 19: Port Status LEDs 35
Figure 20: Port Status LEDs 35
Figure 21: Inserting an SFP/SFP+/QSFP+ Transceiver into a Slot 37
Figure 22: RJ-45 Connector 38
Figure 23: Making Connections to an SFP+ Transceiver 41
Figure 24: Connecting to a QSFP+ Transceiver 43
Figure 25: Making DAC Connections 45
Figure 26: System LEDs 48
Figure 27: Management Port 49
Figure 28: Console Port 50
Figure 29: Console Port Connection 51

Edge-Core AS5610-52X Specifications

Operating Environment

operating temperature	0° C to 40° C
storage temperature	-40° C to 70° C
operating humidity	5% to 95% (non-condensing)

Power

AC input voltage	100-240 VAC
AC input frequency	50-60 Hz
AC input current	6-3 A
DC output 5V	3 A
DC output 12V	33 A
power consumption	165 Watts maximum
maximum current at 100 VAC	6 A
maximum current at 240 VAC	3 A
power supply power	400 Watts @ 240V/100V per module

Weight and Dimensions

width	438.4 mm
depth	473 mm
height	43.4 mm
weight	8.395 kg
power supply width	54.5 mm
power supply depth	220 mm
power supply height	40.25 mm
