Edge-Core AS5610-52X Installation Guide

Installation Guide
ECS5610-52S 48-Port 10G Top-of-Rack Switch
with 48 10GBASE SFP+ Ports,
4 40GBASE QSFP+ Ports,
1 1000BASE-T (RJ-45) Management Port,
2 Power Supply Units (F2B and B2F Airflow),
and 1 Fan Tray Module (F2B and B2F Airflow)
E062013-KS-R01
150200000495A

Edge-Core AS5610-52X Specifications

Operating Environment

operating temperature	0° C to 40° C
storage temperature	-40° C to 70° C
operating humidity	5% to 95% (non-condensing)

Power

AC input voltage	100-240 VAC
AC input frequency	50-60 Hz
AC input current	6-3 A
DC output 5V	3 A
DC output 12V	33 A
power consumption	165 Watts maximum
maximum current at 100 VAC	6 A
maximum current at 240 VAC	3 A
power supply power	400 Watts @ 240V/100V per module

Weight and Dimensions

width	438.4 mm
depth	473 mm
height	43.4 mm
weight	8.395 kg
power supply width	54.5 mm
power supply depth	220 mm
power supply height	40.25 mm
