Edge-Core AS5610-52X Installation Guide

Chapter 5 | Port Connections
How to Install an SFP/SFP+/QSFP+ Transceiver
– 36 –
How to Install an SFP/SFP+/QSFP+ Transceiver
The switch provides slots for optional SFP, SFP+, and QSFP+ transceivers. The
supported transceiver types are listed below:
◆ 40 Gbps Ethernet QSFP+ transceivers
■
40GBASE-CR4
■
40GBASE-SR4
◆ 10 Gbps Ethernet SFP+ transceivers
■
10GBASE-CR
■
10GBASE-SR
■
10GBASE-LR
■
10GBASE-LRM
◆ 1000 Mbps Ethernet SFP transceivers
■
1000BASE-SX
■
1000BASE-LX
Note: SFP/SFP+/QSFP+ transceivers are hot-swappable. The switch does not need
to be powered off before installing or removing a transceiver.
Note: SFP/SFP+/QSFP+ transceivers are not provided in the switch package.
To install an SFP/SFP+/QSFP+ transceiver, do the following:
1. Consider network and cabling requirements to select an appropriate
transceiver type that is also compatible with the switch transceiver support.
2. If the SFP/SFP+/QSFP+ slot is covered with a rubber protective cap, remove the
cap and keep it for later replacement.
3. Insert the transceiver with the optical connector facing outward and the slot
connector facing down. Note that SFP/SFP+/QSFP+ transceivers are keyed so
they can only be installed in the correct orientation.
4. Slide the transceiver into the slot until it clicks into place. If you do not
immediately connect a cable to the port, use a rubber protective cap to keep
the transceiver optics clean.

Edge-Core AS5610-52X Specifications

Operating Environment

operating temperature	0° C to 40° C
storage temperature	-40° C to 70° C
operating humidity	5% to 95% (non-condensing)

Power

AC input voltage	100-240 VAC
AC input frequency	50-60 Hz
AC input current	6-3 A
DC output 5V	3 A
DC output 12V	33 A
power consumption	165 Watts maximum
maximum current at 100 VAC	6 A
maximum current at 240 VAC	3 A
power supply power	400 Watts @ 240V/100V per module

Weight and Dimensions

width	438.4 mm
depth	473 mm
height	43.4 mm
weight	8.395 kg
power supply width	54.5 mm
power supply depth	220 mm
power supply height	40.25 mm
