Edge-Core AS5610-52X Installation Guide

– 5 –
Contents
How to Use This Guide 3
Contents 5
Figures 7
Tables 9
1 Switch Description 10
Overview 10
Key Hardware Components 11
Key Technical Specifications 13
Data Center Deployment 14
Rack Cooling 15
2 Installation Overview 18
Package Contents 18
Switch Installation Tasks 19
3 Switch Chassis 23
General Installation Guidelines 23
How to Install the Switch in a Rack 24
Rack-Mounting Items 24
Rack-Mount Procedure 24
Switch Cooling Requirements 26
Rack Cooling 27
Fan Tray Module 27
How to Replace a Fan Tray 28
4 Power and Grounding 29
Power Supply Modules 29
Grounding the Chassis 31
How to Connect to AC Power 31

Edge-Core AS5610-52X Specifications

Operating Environment

operating temperature	0° C to 40° C
storage temperature	-40° C to 70° C
operating humidity	5% to 95% (non-condensing)

Power

AC input voltage	100-240 VAC
AC input frequency	50-60 Hz
AC input current	6-3 A
DC output 5V	3 A
DC output 12V	33 A
power consumption	165 Watts maximum
maximum current at 100 VAC	6 A
maximum current at 240 VAC	3 A
power supply power	400 Watts @ 240V/100V per module

Weight and Dimensions

width	438.4 mm
depth	473 mm
height	43.4 mm
weight	8.395 kg
power supply width	54.5 mm
power supply depth	220 mm
power supply height	40.25 mm
