Edge-Core AS5610-52X Installation Guide

How to Use This Guide
– 4 –
◆ Chapter 5 - Port Connections — Includes information on network interfaces,
installing optional transceivers, and cabling specifications.
◆ Chapter 6 - Switch Management — Connecting to the switch for management,
and information on the system status LEDs.
◆ Appendix A - Troubleshooting — Information for troubleshooting switch
installation and operation.
Related
Documentation
This guide focuses on switch hardware and installation, it does not cover software
configuration of the switch. For specific information on how to operate and use the
management functions of the switch, see the following guides:
CLI Command Reference
Administrator’s Guide
For all safety information and regulatory statements, see the following document:
Quick Start Guide
Safety and Regulatory Information
Conventions The following conventions are used throughout this guide to show information:
Note: Emphasizes important information or calls your attention to related features
or instructions.
Caution: Alerts you to a potential hazard that could cause loss of data, or damage
the system or equipment.
Warning: Alerts you to a potential hazard that could cause personal injury.
Revision History This section summarizes the changes in each revision of this guide.
April 2013 Revision
This is the first revision of this guide.

Edge-Core AS5610-52X Specifications

Operating Environment

operating temperature	0° C to 40° C
storage temperature	-40° C to 70° C
operating humidity	5% to 95% (non-condensing)

Power

AC input voltage	100-240 VAC
AC input frequency	50-60 Hz
AC input current	6-3 A
DC output 5V	3 A
DC output 12V	33 A
power consumption	165 Watts maximum
maximum current at 100 VAC	6 A
maximum current at 240 VAC	3 A
power supply power	400 Watts @ 240V/100V per module

Weight and Dimensions

width	438.4 mm
depth	473 mm
height	43.4 mm
weight	8.395 kg
power supply width	54.5 mm
power supply depth	220 mm
power supply height	40.25 mm
