Edge-Core AS5610-52X Installation Guide

– 18 –
2 Installation Overview
This chapter includes these sections:
◆ “Package Contents” on page 18
◆ “Switch Installation Tasks” on page 19
Package Contents
After unpacking the switch, check the contents to be sure you have received all the
components.
◆ ECS5610-52S 10G Top-of-Rack Switch
◆ Rack Mounting Kit containing two brackets and eight screws for attaching the
brackets to the switch
◆ Power cord—either US, Continental Europe or UK
◆ Console cable (RJ-45 to DB-9)
◆ Quick Start Guide
◆ Regulatory and Safety Information
◆ Documentation CD—includes Installation Guide and Management Guide

Edge-Core AS5610-52X Specifications

Operating Environment

operating temperature	0° C to 40° C
storage temperature	-40° C to 70° C
operating humidity	5% to 95% (non-condensing)

Power

AC input voltage	100-240 VAC
AC input frequency	50-60 Hz
AC input current	6-3 A
DC output 5V	3 A
DC output 12V	33 A
power consumption	165 Watts maximum
maximum current at 100 VAC	6 A
maximum current at 240 VAC	3 A
power supply power	400 Watts @ 240V/100V per module

Weight and Dimensions

width	438.4 mm
depth	473 mm
height	43.4 mm
weight	8.395 kg
power supply width	54.5 mm
power supply depth	220 mm
power supply height	40.25 mm
