Chapter 10

| Interface Commands

Cable Diagnostics

– 388 –

Example

Console#show loop internal interface ethernet 1/1

Port Test Result Last Update

-------- -------------- --------------------

Eth 1/1 Succeeded 2013-04-15 15:26:56

Console#
