Chapter 23
| LLDP Commands
– 677 –
ETS Configuration
Willing : False
CBS : False
Number of TCs supported : 3
Priority Assignment Table : [0]00 [1]00 [2]00 [3]00
[4]00 [5]00 [6]00 [7]00
Traffic Class Bandwidth(Hex) : [0]00 [1]00 [2]00 [3]00
: [4]00 [5]00 [6]00 [7]00
Traffic Selection Algorithm : [0]0 [1]0 [2]0 [3]0
: [4]0 [5]0 [6]0 [7]0
: [4]0 [5]0 [6]0 [7]0
PFC Configuration
Willing : False
MBC : True
Max PFC classes supported : 8
PFC Enable Vector : [0]0 [1]0 [2]0 [3]0 [4]0 [5]0 [6]0 [7]0
---------------------------------------------------------------
Local Port Name : Eth 1/1
Chassis Type : MAC Address
Chassis ID : 00-01-02-03-04-05
Port ID Type : Network Address
Port ID : 00-01-02-03-04-06
System Name :
System Description :
System Description : ECS5110-12M
SystemCapSupported : Bridge
SystemCapEnabled : Bridge
Remote Management Address :
192.168.1.2 (IPv4)
Remote Port VID : 1
Remote Port-Protocol VLAN :
VLAN-3 : supported, enabled
Remote VLAN Name :
VLAN-1 : DefaultVlan
Remote Protocol Identity (Hex) :
88-CC
Remote MAC/PHY Configuration Status :
Remote port auto-neg supported : Yes
Remote port auto-neg enabled : Yes
Remote port auto-neg advertised cap (Hex) : 0000
Remote port MAU type : 6
Remote Power via MDI :
Remote power class : PSE
Remote power MDI supported : Yes
Remote power MDI enabled : Yes
Remote power pair controllable : No
Remote power pairs : Spare
Remote power classification : Class1
Remote Link Aggregation :
Remote link aggregation capable : Yes
Remote link aggregation enable : No
Remote link aggregation port ID : 0
Remote Max Frame Size : 1518
LLDP-MED Capability :
Device Class : Network Connectivity
Supported Capabilities : LLDP-MED Capabilities
Network Policy
Location Identification
Extended Power via MDI - PSE
Inventory
Current Capabilities : LLDP-MED Capabilities
