Chapter 23

| LLDP Commands

– 679 –

Eth 1/2 11 12 0

Eth 1/3 0 0 0

Eth 1/4 0 0 0

Eth 1/5 0 0 0

.

.

.

Console#show lldp info statistics detail ethernet 1/1

LLDP Port Statistics Detail

Port Name : Eth 1/1

Frames Discarded : 0

Frames Invalid : 0

Frames Received : 327

Frames Sent : 328

TLVs Unrecognized : 0

TLVs Discarded : 0

Neighbor Ageouts : 0

Console#
