1. TECHNICAL SPECIFICATIONS
AC INPUT DATA
NOMINAL AC VOLTAGE (GRID | GENERATOR)
120/240VAC; 120/208VAC (L1/L2/N required)
FREQUENCY (GRID | GENERATOR)
60 Hz (Default) | 50 Hz (Configurable)
GRID MAX. CONTINUOUS AC CURRENT
100A @ 240VAC
MAX. AC INPUT POWER
24000W
GENERATOR MAX. CONTINUOUS CURRENT
62.5A @ 240VAC
RECOMMENDED GENERATOR CAPACITY
6000W – 15000W
AC BYPASS (GRID | GENERATOR)
100A | 90A
AC OUTPUT DATA
OUTPUT VOLTAGE
120/240VAC; 120/208V
OUTPUT FREQUENCY
60 Hz (Default) | 50 Hz (Configurable)
MAX. CONTINUOUS OUTPUT CURRENT
50A @ 240VAC | 57.5A @ 208V
NOMINAL POWER OUTPUT
w/ PV: 12000W @ 240V | 12000W @ 208V
w/ out PV: 12000W @ 240V | 12000W @ 208V
MAX. CONTINUOUS WATTAGE
12000W (L1-L2) | 6000W (L1-N or L2-N)
PEAK POWER (SURGE CAPACITY)
18000W for ≈5 seconds | 15000W for ≈10s
POWER FACTOR VALUE
.99
OPERATING FREQUENCY
60 Hz (Default) | 50 Hz (Configurable)
THD (V)
<3%
SWITCHING TIME
<10 ms @ Single / <20 ms @ Parallel
PV INPUT DATA
NUMBER OF MPPTS
2
INPUTS PER MPPT
2/2
MAX. USABLE INPUT CURRENT 35A/35A
MAX. SHORT CIRCUIT INPUT CURRENT
44A/44A
DC INPUT VOLTAGE RANGE
100 – 480VDC
MIN. STARTUP VOLTAGE 100VDC
MPPT OPERATING VOLTAGE RANGE
120 – 385VDC
NOMINAL MPPT VOLTAGE
320VDC
MAX. UTILIZED SOLAR POWER 24000W (12000 per MPPT)
MAX. RECOMMENDED SOLAR INPUT
28000W (14000 per MPPT)
