EG4 12000XP - Battery Data; General Data; Standards and Certifications

2
EFFICIENCY
MAXIMUM EFFICIENCY (MPPT)
99%
MAXIMUM EFFICIENCY (PV TO BATTERY)
92.8%
MAXIMUM EFFICIENCY (AC TO BATTERY)
92.5%
MAXIMUM EFFICIENCY (PV TO LOADS)
93.5%
MAXIMUM EFFICIENCY (BATTERY TO LOADS)
90.2%
IDLE CONSUMPTION (STANDBY MODE)*
<70W
BATTERY DATA
COMPATIBLE TYPES
Lead-Acid/Lithium
MAX. CHARGE/DISCHARGE CURRENT (A)
250A
MAX. CHARGE/DISCHARGE POWER (W)
12000W
NOMINAL VOLTAGE
48VDC
BATTERY VOLTAGE RANGE
46.4 – 60 VDC (Lithium) | 38.4 – 60 VDC (Lead-Acid)
RECOMMENDED BATTERY CAPACITY PER INVERTER
>400Ah
HIGH DC CUT-OFF VOLTAGE
59 VDC (Lithium) | 60 VDC (Lead-acid)
GENERAL DATA
MAX. UNITS IN PARALLEL
6
PRODUCT DIMENSIONS (H×W×D)
34.25×20.87×5.91 in. (870×530×150 mm)
UNIT WEIGHT
104.7 lbs. (47.5 kg)
DESIGN TOPOLOGY
High Frequency - Transformerless
RELATIVE HUMIDITY
5 – 95% (non-condensing)
OPERATING ALTITUDE
<6561 ft. (<2000 m)
OPERATING AMBIENT TEMPERATURE RANGE
32°F – 113°F (0°C – 45°C) @ Full Load
STORAGE AMBIENT TEMPERATURE RANGE
5°F – 140°F (-15°C – 60°C)
NOISE EMISSION (TYPICAL)
<60
dB
COOLING METHOD
Fan
COMMUNICATION INTERFACE
RS485/CAN/Wi-Fi
STANDARD WARRANTY**
5-year standard warranty
INGRESS PROTECTION RATING IP20
SAFETY FEATURES
PV Reverse Polarity Protection,
Surge Protection Device, Output Over-Voltage Protection,
Output Over-Voltage Protection Varistor
STANDARDS AND CERTIFICATIONS
UL1741
*Idle consumption value tested with constant 300 VDC PV source
**See EG4 Warranty Registration for terms and conditions
